Yamaha StagePas 100 Portable PA System

Description

Yamaha StagePas 100 Portable PA System

Portable PA system equipped with a 100 W power amp, coaxial compression driver with 1.4” voice coil HF and 6.5” cone LF, and a 3-channel mixer.

FEATURES

• 100 W Class-D amplifier
• 1.4” HF + 6.5” LF high-quality coaxial compression driver using an FIR filter for the crossover
• 3-channel mixer (2 monaural mic/line + 1 line)
• Equipped with a 2-band master EQ
• Compatible with Hi-Z input (Channel 2 only)
• Equipped with mix-out
• Carrying handle doubles as an adjustable stand
• Compatible with audio accompaniment over Bluetooth
• Optional carrying bag (BAG-STP100) available for convenient transport

SPECIFICATIONS

• Outline
• Type
• 2-way Bi-amp Powered Speaker with mixer
• I/O
• Inputs
• INPUT 1: Combo (mic/line), INPUT 2: Combo (mic/line), INPUT 3: Stereo Mini x1 (line)
• Outputs
• OUTPUT: XLR3-32 (INPUT 1-3 mix)
• Bluetooth
• Ver.5.0, A2DP (SBC, AAC), Class 1
• Mixing capability
• Mixing channels
• 3
• Input channel functions
• Hi-Z: CH2
• Output channel functions
• 2 Band EQ
• General specifications
• Speaker type
• Coaxcial speaker with compression driver
• Frequency range (-10dB)
• 70 Hz – 20 kHz
• Coverage area
• H90ﾟ x V90ﾟ
• Crossover
• 1.8 kHz (FIR-X)
• Maximum output level (1m; on axis)
• 120 dB SPL *1
• Components
• LF
• 6.5″ Cone, 1.7″ voice coil
• HF
• 1″ throat compression driver, 1.4″ voice coil
• Amplifier class
• Class-D
• Power rating
• Dynamic
• 100 W (LF: 93 W, HF: 7 W)
• Cooling
• Natural convection (no fan)
• Power consumption
• 10 W (Idle), 30 W (1/8 power)
• Power requirements
• 100-240 V 50/60 Hz
• Battery
• Type
• –
• Capacity
• –
• Operating Time
• –
• Charging Time
• –
• Cabinet material
• Plastic (PP)
• Handle
• Bottom x1 (Rotatable)
• Flying and mounting hardware
• 1 × 3/8″, depth 12 mm (center of handle)
• Dimensions (W x H x D)
• 239 x 310 x 215 mm (9.5″ x 12.3″ x 8.5″), with handle
• Weight
• 5.2 kg (11.5 lbs), without AC adaptor
• Accessories
• Power cord x 1, AC adaptor (PA-500) x 1
• Options
• Carrying bag: BAG-STP100

Product Dimension Shipping Weight: 9.0 kg
