TOA A-230 PA Amplifier

Description

TOA A-230 PA Amplifier (A230)

The PA Amplifier A-230, designed to fulfill requirement arrange voice like paging, oration, ceremony,inter communication, religious service place, car- calling, and others.

SPECIFICATIONS

• Power Source
• 220 – 230 V AC, or 12 V DC
• Rated Output
• 30 W
• Power Consumption
• 34 W (AC operation at IEC60065)
• Current Consumption
• 4.5 A (DC operation at rated output)
• Frequency Response
• 50 Hz – 20 kHz
• Distortion
• 1 % or less at 1 kHz, 1/3 rated power
• Input
• MIC 1 – 3: -60 dB* (1.0 mV), 600 Ω, unbalanced, phone jack
• AUX: -20 dB* (100 mV), 10 kΩ, unbalanced, RCA pin jack
• Output
• Speaker out: Floating balanced
• High impedance: 330 Ω (100 V)
• Low impedance: 4 Ω (11 V)
• Signal to Noise Ratio
• 60 dB or more (MIC 1 – 3)
• 70 dB or more (AUX)
• Tone Control
• Bass: -10 dB at 100 Hz
• Treble: -10 dB at 10 kHz
• Muting
• MIC 1 overrides other Mic inputs and AUX input with 0 – 30 dB attenuation, attenuation by MIC 1 input
• Indicator
• Power LED, Signal LED
• Operating Temperature
• -10 ℃ to +40 ℃ (14 ゜F to 104 ゜F)
• Finish
• Panel: ABS resin, black Hairline
• Case: Steel plate, black, paint
• Dimensions
• 350 (W) × 105 (H) × 240 (D) mm (13.78″ × 4.13″ × 9.45″)
• Weight
• 3.5 kg (7.72 lb)

Product Dimension Shipping Weight: 4.8 kg
