Neumann KM 183 Omnidirectional Small-diaphragm Condenser Microphone – Nickel

Description

Neumann KM 183 Omnidirectional Small-diaphragm Condenser Microphone – Nickel (KM183NI)

The KM 183 is a state-of-the-art small diaphragm condenser microphone with a frequency-independent omnidirectional polar pattern. Its very natural, transparent sound with very low self-noise and high SPL capability have made the KM 183 a worldwide studio standard for many applications ranging from classical piano to heavy metal drums.

FEATURES

• Omnidirectional polar pattern with excellent off-axis behavior
• Diffuse-field equalized
• Pressure transducer with unlimited bass response
• Very low self-noise (13 dB-A)
• Transformerless circuitry
• Compact size, visually unobtrusive

SPECIFICATIONS

• Acoustical operating principle : Pressure transducer
• Directional Patter : Omnidirectional
• Frequency Range : 20 Hz 20 kHz
• Sensitivity at 1 kHz into 1 kohm : 12 mV/Pa ± 1 dB
• Rated Impedance : 50 ohms
• Rated load impedance : 1 kohms
• Equivalent noise level, CCIR¹⁾ : 24 dB
• Equivalent noise level, A-weighted¹⁾ : 13 dB-A
• Maximum SPL for THD 0.5%²⁾ : 140 dB
• Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾ : 70 dB
• Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾ : 81 dB
• Maximum output voltage : 10 dBu
• Supply voltage (P48, IEC 61938) : 48 V ± 4 V
• Current consumption (P48, IEC 61938) : 3.2 mA
• Matching connector : XLR 3 F
• Weight : approx. 80 g
• Diameter : 22 mm
• Length : 107 mm

Product Dimension Shipping Weight: 0.5 kg
